The AUTOMATIC HONEYCOMB PAPER CUTTING MACHINE efficiently converts kraft paper into eco-friendly honeycomb wrap with high-speed precision die-cutting. Featuring PLC control, HMI touch screen, and automatic unwinding, it boosts productivity, reduces labor costs, and delivers recyclable, biodegradable packaging for sustainable shipping needs.
The Automatic Honeycomb Paper Cutting Machine is a sophisticated piece of equipment integral to modern, sustainable packaging operations. This machine automates the production of honeycomb paper, a leading eco-friendly and cost-effective alternative to plastic bubble wrap and foam. It is designed for the high-speed, precision die-cutting of kraft paper rolls into a specific pattern that, when stretched, expands into a three-dimensional honeycomb structure. This expanded mesh provides excellent cushioning, shock absorption, and surface protection for a wide range of products during shipping and handling.
The machine’s operation is highly automated, typically managed by a PLC (Programmable Logic Controller) and an HMI touch screen for simple and efficient use. Its core process involves several key stages: an unwinding system, often with an automatic ultrasonic web guide controller and tension control, feeds a large roll of kraft paper into the machine. The paper then passes through a die-cutting unit, where specially designed blades or rollers create the precise hexagonal pattern. Following the cutting, the paper is processed by a slitting and rewinding machine to be wound into finished rolls of various widths and lengths.
Key features often include an inverter for speed regulation, an automatic meter counting device that stops the machine at a preset length, and sometimes an option for roll-to-sheet cutting. These machines can handle various paper weights, typically from 70g to 120g, and can be integrated into a larger honeycomb paperboard lamination line.
The adoption of an automatic honeycomb paper cutting machine provides numerous benefits. It significantly boosts productivity and efficiency while reducing labor costs by automating what would otherwise be a manual process.The resulting honeycomb wrap is lightweight, which can lower shipping costs, and reduces the need for storage space compared to bulky plastic packaging. As a plastic-free solution, the paper is recyclable, biodegradable, and compostable, meeting the growing demand from consumers and industries like e-commerce and logistics for environmentally responsible packaging.
Product Detailed Parameters
Fully automatic honeycomb paper cutting machine
Applicable Materials
80 gsm Kraft Paper
Unwind Width
≦ 540mm
Unwind Diameter
≦1250mm
Winding Speed
5-250m/min
Winding Width
≦500mm
Unwinding reel
Shaftless pneumatic cone top device
Fits cores
Three inch or six inch
Power supply voltage
22V-380V 50HZ
Total power
6 KW
Mechanical Weight
2500kg
Equipment Color
White with Grey and Yellow
Mechanical Dimension
4840mm*2228mm*2100mm
14 mm thick Steel Slates for The Whole Machine,(The machine is plastic sprayed.)
INNO-FCL-1200
