The INNO-PCL-500A Automatic Honeycomb Paper Making Machine by Innopack transforms kraft paper rolls into eco-friendly Hexcel wrap through high-speed precision die-cutting. Equipped with PLC control, HMI interface, and automatic tension systems, it produces recyclable, biodegradable, and compostable honeycomb paper that offers superior shock absorption and surface protection for e-commerce, logistics, and manufacturing packaging needs.
Model
INNO-PCL-500A
Material
Kraft Paper
Speed
5–250 meters/min
Width Range
≤540 mm
Control
PLC + Inverter + Touch Screen
Application
Honeycomb paper production for protective packaging
The Automatic Honeycomb Paper Making Machine from InnoPack is an advanced, high-speed system designed to produce Hexcel wrap, a revolutionary eco-friendly alternative to traditional plastic packaging materials like bubble wrap. The machine is equipped with precision die-cutting technology, automatic tension control, and a PLC control system for efficient, precise operation. The result is a high-performance machine that creates expandable honeycomb structures for protecting fragile goods during shipping and handling, making it an essential tool in modern sustainable packaging solutions.
Product Introduction
The Automatic Honeycomb Paper Making Machine (INNO-PCL-S00A) is designed to convert kraft paper rolls into Hexcel wrap, a high-performance, eco-friendly cushioning material that serves as a direct replacement for plastic bubble wrap. It utilises precision die-cutting similar to that used in our paper folding machinery to create its unique structure. The machine uses a precision-driven die-cutting process, where large rolls of kraft paper are unwound, and the paper is passed through a high-pressure die-cutting roller to cut repeating hexagonal patterns into the material. These patterns create a three-dimensional expandable honeycomb structure that provides exceptional shock absorption, surface protection, and impact resistance for fragile products.
The machine is controlled by a PLC system, providing seamless operation with precise control over cutting parameters, speed, and roll length. The process is automated, with automatic meter counting and servo motor drives ensuring high efficiency, minimal waste, and consistent product quality. The honeycomb paper produced by the machine is lightweight, biodegradable, compostable, and 100% recyclable, making it an environmentally responsible choice for packaging.
The machine is capable of handling different widths of paper, and the rolls can be customized to suit the needs of businesses in e-commerce, logistics, and manufacturing industries.
Technical Specifications
Fully automatic honeycomb paper cutting machine
Applicable Materials
80 gsm Kraft Paper
Unwind Width
≦ 540mm
Unwind Diameter
≦1250mm
Winding Speed
5-250m/min
Winding Width
≦500mm
Unwinding reel
Shaftless pneumatic cone top device
Fits cores
Three inch or six inch
Power supply voltage
22V-380V 50HZ
Total power
6 KW
Mechanical Weight
2500kg
Equipment Color
White with Grey and Yellow
Mechanical Dimension
4840mm*2228mm*2100mm
14 mm thick Steel Slates for The Whole Machine,(The machine is plastic sprayed.)
Air Source
Auxiliary
Key Features
Precision Die-Cutting Technology The machine’s high-pressure die-cutting roller creates precise, repeating hexagonal patterns in the paper, which form the expandable honeycomb structure.
Automated Operation The machine operates with PLC automation and HMI (Human-Machine Interface), offering full control over production speed, roll length, and cutting accuracy.
High-Speed Production With a winding speed of 5–250 m/min, the machine is capable of producing large quantities of honeycomb paper in a short amount of time, enhancing overall productivity.
Sustainable Packaging The resulting Hexcel wrap is a fully recyclable, biodegradable, and compostable material, positioning this machine as a leader in the eco-friendly packaging industry. It can be used alongside other sustainable cushioning materials like paper air pillows and paper air bubble rolls to create a complete plastic-free packaging solution.
Customizable Roll Sizes The machine allows for the creation of custom roll widths and lengths, making it ideal for a variety of products and industries, from fragile goods to heavy-duty materials.
Advanced Tension and Web Guide System The machine features automatic tension control and a web guide system, ensuring smooth paper unwinding, minimal waste, and consistent quality—a critical feature also employed in our high-speed corrugated mailer production lines.
Servo Motor Drives Servo motor drives ensure high precision in feeding, cutting, and slitting, improving the machine’s overall speed and efficiency.
Lightweight, Durable Packaging The honeycomb paper produced is lightweight but durable, offering superior protection without taking up excessive storage space or adding unnecessary weight during shipping.
Applications
E-commerce packaging for fragile goods such as electronics, glassware, and cosmetics
Logistics packaging for shipping delicate items
Manufacturing industries requiring cushioning materials for parts and components
Packaging for high-end retail products
Protective packaging for artwork, documents, and other sensitive items
Eco-friendly alternatives to bubble wrap and foam, providing superior void-fill and surface protection when used inside premium glassine paper mailers or standard kraft paper mailers.
Why Choose Us
InnoPack is a leading innovator in automated packaging systems, specializing in sustainable and high-performance machinery. Our Automatic Honeycomb Paper Making Machine is engineered to meet the growing demand for eco-friendly packaging solutions, providing businesses with a reliable and cost-effective method to produce high-quality honeycomb wrap.
By choosing InnoPack and exploring InnoPack’s full range of sustainable machinery, you are investing in cutting-edge packaging technology. Pair this making machine with our Automatic Honeycomb Paper Cutting Machine for a complete honeycomb production line. Our machines are designed for efficiency, precision, and sustainability, ensuring that your business remains at the forefront of the sustainable packaging movement.
Conclusion
The Automatic Honeycomb Paper Making Machine by InnoPack is the ultimate solution for businesses looking to produce sustainable, durable, and cost-effective packaging. With its precision die-cutting technology, automatic operation, and ability to create expandable honeycomb structures, this machine sets the standard for modern eco-friendly packaging solutions. Investing in InnoPack’s machinery, from this maker to the Fully Automatic Hexcell Paper Cutting Machine, means improving operational efficiency while replacing unsustainable materials like plastic air pillows.
FAQs
What materials can the machine handle? The machine processes kraft paper to create honeycomb paper, which can be used for packaging, filtration, and cushioning.
Can the machine be customized to produce different bag sizes? Yes, the Automatic Honeycomb Paper Making Machine can create different roll sizes based on your specific requirements.
How fast is the production process? The machine operates at a speed of 5–250 meters per minute, making it suitable for high-volume production.
What industries use honeycomb paper? Honeycomb paper is widely used in e-commerce, logistics, manufacturing, and art preservation.
Is the honeycomb paper eco-friendly? Yes, the paper is 100% recyclable, biodegradable, and compostable, making it an environmentally responsible choice for businesses.
Field Insight
As businesses seek to reduce their environmental footprint, eco-friendly packaging solutions like honeycomb paper have become increasingly popular. InnoPack’s Automatic Honeycomb Paper Making Machine provides a high-speed, efficient, and sustainable alternative to plastic-based packaging. By automating the production of high-quality honeycomb paper, businesses can enhance productivity, reduce labor costs, and meet the growing consumer demand for environmentally responsible packaging options.
