The CORRUGATED PADDED MAILER MACHINE INNO-PCL-1200C is an advanced, fully automated solution for producing eco-friendly fluted paper and corrugated mailers. Designed for e-commerce, logistics, and express delivery, it combines corrugation, lamination, sealing, and cutting into a seamless workflow, controlled by PLC and HMI systems. This high-speed machine delivers lightweight, durable, and recyclable mailers that reduce shipping costs and meet growing sustainability demands.
Model
INNO-PCL-1200C
Material
Kraft Paper
Speed
100 pcs/min (200 pcs/min double out)
Width Range
≤700 mm
Control
PLC + Inverter + Touch Screen
Application
Corrugated padded mailer production for protective packaging
The Corrugated Padded Mailer Machine from InnoPack is a high-speed automated system designed for producing fluted paper mailers used in the e-commerce, logistics, and express delivery sectors. These eco-friendly, recyclable mailers provide excellent protection for goods during transit, making them a sustainable alternative to plastic bubble mailers. The machine is equipped with advanced PLC control, motion control technology, and servo motors to ensure precise production and efficient packaging.
Product Introduction
The Corrugated Padded Mailer Machine (INNO-PCL-1200C) is engineered to automate the production of high-quality corrugated mailers used in protective packaging. It creates a more robust alternative to single-layer kraft paper mailers and glassine paper mailers, providing built-in cushioning that eliminates the need for external plastic bubble wrap. The machine processes multiple rolls of kraft paper, corrugating one layer to create shock-absorbing inner padding. This is then laminated between two outer layers of kraft paper using a precise gluing system, making it ideal for the production of mailers that are both durable and lightweight.
Controlled by a PLC and HMI touchscreen, the machine operates with high precision, ensuring consistent quality in every mailer. Advanced servo motors and motion control technology handle key functions such as unwinding, corrugation, pressing, sealing, and cutting. The machine offers high-speed production capabilities, making it perfect for high-volume packaging environments, particularly in e-commerce fulfillment and logistics.
By producing fluted paper mailers, this machine helps companies reduce their reliance on plastic packaging, contributing to sustainable and eco-friendly packaging solutions. The mailers are tear-resistant, recyclable, and often biodegradable, meeting consumer demand for environmentally responsible packaging.
Technical Specifications
Model No:
INNO-PCL-1200C
Unwinding width
≤1400mm
Unwindingdiameter
≤1200mm
Bag Length
≤700mm
Bag width
≤700mm
Production speed
100PCS/min (200 pcs / min double out)
Total power
43.5Kw
Machine weight
140000Kg
Dimensions
19000×2200×2250mm
Key Features
Fully Automated Operation The Corrugated Padded Mailer Machine is controlled by a PLC with an intuitive HMI touchscreen for easy operation, a standard across InnoPack’s other PLC-controlled machineslike our paper folding systems.
High-Speed Production With a production speed of up to 100 pcs/min (200 pcs/min double out), the machine is designed for high-volume production environments.
Precision Die-Cutting and Laminating The machine incorporates a high-precision die-cutting unit, ensuring that each mailer is cut accurately and consistently. The gluing system uses hot melt or cold glue to laminate the paper layers securely.
Motion Control and Servo Motors Advanced motion control technology and servo motors ensure precise material feeding, tension control, and consistent laminating and cutting, providing top-quality results in every batch.
Right-Sizing Technology The machine features right-sizing technology that minimizes material waste and reduces shipping costs by producing mailers of varying lengths to fit specific product sizes.
Eco-Friendly Packaging Solution The corrugated padded mailers produced by this machine are a sustainable, biodegradable, and recyclable alternative to traditional plastic packaging materials. For additional void-fill protection, they can be used with paper air pillowsor cut honeycomb paper, creating a fully sustainable packaging system.
Inline Printing and Self-Sealing Options The machine can be equipped with inline printing for branding and a self-sealing adhesive strip for convenience and ease of use.
Tear-Resistant Packaging The machine produces tear-resistant mailers that ensure goods are securely protected during transit and are less likely to be damaged.
Applications
E-commerce packaging for fragile products such as electronics, cosmetics, and glassware
Logistics packaging solutions for shipping and handling delicate items
Express delivery services requiring fast, secure, and sustainable packaging
Industrial packaging for products that need protection from impact and vibration during transportation
Packaging for consumer goods in retail and wholesale sectors
Why Choose Us
InnoPack is a leading manufacturer of packaging machinery, specializing in solutions that meet the growing demand for eco-friendly and sustainable packaging. With years of expertise and a commitment to innovation, InnoPack delivers high-performance machines that automate and optimize packaging production, improving efficiency and reducing costs. Our Corrugated Padded Mailer Machine is designed to provide exceptional performance in high-speed, high-volume environments, making it a top choice for industries seeking to adopt sustainable packaging solutions.
The Corrugated Padded Mailer Machine by InnoPack is an advanced, fully automated solution for producing high-quality, eco-friendly corrugated padded mailers. This offers a sustainable alternative to mailers that require internal plastic air pillows for protection. By using kraft paper to create corrugated mailers, this machine provides cost-effective, tear-resistant, and recyclable packaging that meets the demands of modern logistics and e-commerce industries. With its high-speed production capabilities and sustainable design, the Corrugated Padded Mailer Machine is an essential investment for businesses looking to enhance their packaging processes while reducing their environmental impact.
FAQs
What materials can the machine handle? The machine is designed to process kraft paper and can handle paper weights from 70g to 120g.
Can the machine produce different sized mailers? Yes, the machine is equipped with right-sizing technology, which allows it to produce mailers of various lengths based on product dimensions.
What is the production speed? The machine operates at speeds of up to 100 pcs/min, with the option for 200 pcs/min double out.
Is the machine easy to operate? Yes, the PLC control system and HMI touchscreen make the machine simple to operate, with real-time parameter adjustments.
How does the machine help with sustainability? By producing recyclable and biodegradable corrugated mailers, the machine reduces the need for plastic bubble mailers and helps businesses meet their sustainability goals.
Field Insight
As the demand for sustainable packaging grows, businesses are increasingly seeking packaging solutions that are not only efficient but also environmentally responsible. InnoPack continues to innovate and lead the way in eco-friendly packaging technology , providing machines that deliver high-speed performance while reducing material waste and carbon footprints. The Corrugated Padded Mailer Machine is a vital tool for businesses looking to transition to greener packaging alternatives without compromising on product protection or shipping efficiency.
