Fully Automatic Hexcell Paper Cutting Machine

Fully Automatic Hexcell Paper Cutting Machine

INNO-PCL-500A

The INNO-PCL-500A Fully Automatic Hexcell Paper Cutting Machine by Innopack is designed for producing honeycomb filter paper, wrapping paper, and kraft fish net paper from 60g to 160g. Featuring interchangeable die-cutting modules, it can create various honeycomb shapes or standard rolls. Equipped with inverter speed control, ultrasonic web guide, and magnetic powder tension system, it integrates unwinding, die-cutting, and rewinding into one automated process, ensuring precision, efficiency, and versatility for eco-friendly packaging and filter applications.

Submit request

   

Description

FULLY AUTOMATIC HEXCELL PAPER CUTTING MACHINE

INNO-PCL-500A

Machine features

Our honeycomb paper cutting machine which can make honeycomb filter paper,the honeycomb shape can be changed by using different die cutting module, and same machine can make normal honeycomb paper on roll too.

This honeycomb filter paper making machine is our newest design accord to customer requirement, the main material of paper is the flame resistant paper or flame retardant paper, after die cutting and stitching online,the finished paper in roll can be used as filter material.

This machine is suitable for die cutting honeycomb paper, wrapping paper, shock-absorbing paper, kraft paper, fish net paper from 60g to 160g.

And The unwinding,cutting and rewinding in one process.

And Main motor equipped with Inverter for speed regulation.

The Automatic ultrasonic web guide controller for unwinding.

It is Tension controlled by magnetic powder brake and clutch.

The honeycomb paper rolls making machine is automatic meter counting device, automatically stop after it reaches the length you set.

Product Detailed Parameters

Fully automatic honeycomb paper cutting machine
Applicable Materials	80 gsm Kraft Paper
Unwind Width	≦ 540mm	Unwind Diameter	≦1250mm
Winding Speed	5-250m/min	Winding Width	≦500mm
Unwinding reel	Shaftless pneumatic cone top device
Fits cores	Three inch or six inch
Power supply voltage	22V-380V 50HZ
Total power	6 KW
Mechanical Weight	2500kg
Equipment Color	White with Grey and Yellow
Mechanical Dimension	*4840mm2228mm2100mm*
14 mm thick Steel Slates for The Whole Machine,(The machine is plastic sprayed.)
Air Source	Auxiliary
