INNO-FCL-200-2
An entirely automated device for creating air column bag packaging materials is the Air Column Bag Film Making Machine.Made of multi-layer co-extruded film, Air Column Bags are a novel kind of cushioning packing material that, when inflated, create independent air columns that can successfully shield goods from impact, extrusion, and vibration while in transit.
1.Automatic Machine controlled by PLC and Inverter. Easy operation control panel
2. Parameter setting effect immediately, tracked by electronic eyes, smooth and accurate.
3. Widely frequency range of inverters are controlling the whole production line, stepless speed changing, individual release and pick up motors make production more smooth and effective.
4. Release and pick up roll holders are using air expansion shaft, easy load and unload.
》Machine speed is up to 25 meters per minute;
》Produced air column rolls are primarily used for protective packaging;
》Using Kraft paper, PE/PA co-extruded film as raw material, suitable for fragile items;
》 All electrical components are from well-known brands, guarantee with high stability of the machine;
》PLC control with touch screen, user friendly;
Since protective packaging keeps delicate or delicate objects protected from harm, it is no secret that it plays a crucial role in many industries.Since its founding, Innopack has made investments in the development of plastic film and plastic bag conversion machines for use in inflatable and air-cushion packaging in response to market demands.In order to create high-quality bubble film bags, air cushion films, bubble padded mailers, bottle protectors, inflatable cushioning materials, and radiant barrier films that can provide exceptional protection or reflective insulation for customer and individual needs, our engineers have created a wide range of customized bubble film machines, including bubble film extrusion lines equipped with either a single screw extruder or twin screw extruder, plastic film laminating machines, plastic bag making machines, poly mailer machines, and additional inflatable packaging equipment.
| Model No.: | INNO-FCL-200-2 | |||
| Material: | PE low pressure material PE high pressure material | |||
| Unwinding Width | ≦600 mm | Unwinding Diameter | ≦750 mm | |
| Speed of Making Bag | 160-180 units /min | |||
| Machine Speed | 190 /min | |||
| Bag Width | ≦600 mm | Bag Length | ≦600 mm | |
| Unwinding Part | Shaftless pneumatic Cone Jacking Device | |||
| Voltage of Power Supply | 22V-380V,50HZ | |||
| Total Power | 12.5 KW | |||
| Machine Weight | 3.2 T | |||
| Machine Dimension | 6660mm*2480mm*1650mm | |||
| 12 mm thick Steel Slates for The Whole Machine | ||||
| Air Supply | Auxiliary Device | |||
