The Air Column LDPE and LLDPE bag Making Machine is a fully automated device for producing air column bag packaging materials. Constructed from multi-layer co-xtruded film, air column bags are a novel type of cushioning packing material that, when inflated, can successfully shield goods from impact, extrusion, and vibration while in transit.
Model
FCL-1200
Material
PE/PA co-extruded film
Speed
50–90 units/min
Width Range
≤1 200 mm
Control
PLC + Inverter + Touch Screen
Application
Air-column bag production for protective packaging
The Plastic Air Column Bag Making Machine by InnoPack is a state-of-the-art solution designed to manufacture high-quality air column bags for protective packaging, complementing our range of plastic air pillow machines and embodying the innovation of InnoPack’s state-of-the-art solutions. Featuring advanced automation, precise control systems, and eco-friendly material compatibility, this machine provides a reliable, efficient way to produce air cushion packaging for fragile goods. Perfect for e-commerce, logistics, and industrial packaging, the machine delivers high-speed performance while ensuring stable production and top-notch air column quality.
Product Introduction
The Plastic Air Column Bag Making Machineis an advanced automatic production system designed to convert PE/PA co-extruded film into durable and protective air column bags. This machine, controlled by a PLC and inverter system, ensures smooth operation with high production efficiency. It utilizes a dual-pipe cooling system, vacuum forming cylinders, and a T-die for consistent thickness and bubble formation, ensuring the protection of delicate items during transit.
Designed for maximum flexibility and ease of operation, the machine can process kraft paper (a key material in our kraft paper mailers), LDPE, and LLDPE materials (shared with our plastic bubble making machines), making it an ideal solution for businesses looking to produce sustainable and reliable packaging materials. With a production speed of up to 25 meters per minute, the Plastic Air Column Bag Making Machine is capable of handling large-scale production while maintaining product quality.
InnoPack has focused on building reliable and customizable packaging machinery to meet the growing demand for eco-friendly air cushion solutions. This machine’s versatility allows manufacturers to create bubble padded mailers, air cushions, and bottle protectors for various industries, including e-commerce, electronics, and industrial packaging.
Technical Specifications
Model No.:
FCL-1200
Material:
PE-PA high pressure material
Unwinding Width
≦1200 mm
Unwinding Diameter
≦650 mm
Speed of Making Bag
50-90 units /min
Machine Speed
110 /min
Bag Width
≦1200 mm
Bag Length
≦450 mm
Unwinding Part
Shaftless pneumatic Cone Jacking Device
Voltage of Power Supply
22V-380V,50HZ
Total Power
35 KW
Machine Weight
5.6T
Machine Dimension
6500mm*2200mm*2130mm
12 mm thick Steel Slates for The Whole Machine
Air Supply
Auxiliary Device
Key Features
High-Performance Vacuum Forming Cylinder The forming cylinder mold is equipped with a vacuum system, ensuring uniform bubble formation and preventing wear due to extended usage. Dual-pipe cooling further enhances the cooling process, providing consistent quality.
Advanced T-Die Design The T-die system precisely controls material thickness, ensuring uniform film and preventing glue leakage. This ensures efficient production with minimal waste.
Screw Design for 100% Recycled Material Use The specially designed screw system enables the use of recycled materials, ensuring that plastics melt completely for uniform bubble formation. For businesses seeking fully paper-based solutions, our paper air pillow making machine offers a complementary sustainable path.
Safety Features and Emergency Stop Equipped with a strict safety system, this machine includes an emergency stop button that halts all functions, including the extruder, roller cylinder, and electrical circuits, ensuring safety during operation.
Automated Homing and Stop Functions Automated homing and stop functions improve machine efficiency and ensure smooth production flow, reducing downtime and errors.
Individual Release and Pick-up Motors The machine uses individual motors for the release and pick-up systems, allowing for stepless speed adjustments and ensuring smoother operation with a wide frequency range of inverters.
Air Expansion Shafts for Roll Loading Air expansion shafts in the release and pick-up systems make it easier to load and unload rolls, improving the machine’s overall efficiency.
High-Speed Production Rate The machine operates at speeds of up to 25 meters per minute, making it suitable for high-volume packaging environments such as e-commerce fulfillment and logistics.
Applications
Protective packaging for electronics, fragile items, and bottles
Eco-friendly packaging for various industries, including retail and automotive
Why Choose Us
InnoPack has a rich history of delivering high-quality, customizable packaging machinery. With extensive investments in R&D and a commitment to sustainability, InnoPack has created a range of machines that cater to the growing demand for eco-friendly packaging solutions. Our machines are built for efficiency, reliability, and safety, ensuring high performance in production while helping companies reduce material waste and improve packaging sustainability.
With InnoPack’s advanced technology and customizable features, businesses can produce top-quality air column bags and cushioning materials. Explore our complete product line, from this machine to honeycomb paper cutting machinery, to build your ideal packaging suite. Our Plastic Air Column Bag Making Machine is ideal for companies looking to increase production capacity, improve packaging quality, and move toward more sustainable packaging solutions.
Conclusion
The Plastic Air Column Bag Making Machine by InnoPack is the ultimate solution for high-speed, sustainable, and efficient production of air column bags used in protective packaging. With its advanced design, precision controls, and eco-friendly material compatibility, it offers companies a reliable way to improve packaging efficiency while reducing their environmental impact. InnoPack continues to provide top-tier machinery designed to meet the demands of the modern packaging industry, from the plastic air pillow making machine to the eco-friendly paper air bubble making machine.
FAQs
What materials can be used with the machine? The machine is designed to process PE/PA co-extruded film, Kraft paper, LDPE, and LLDPE materials for air column bag production. For dedicated paper air pillow production, please refer to our specialized machine.
Can the machine handle small production runs? Yes. The machine is highly versatile and can handle both large-scale production and small batch runs, making it suitable for various business needs.
How easy is it to operate the machine? The machine is controlled via a PLC and touch screen, with a user-friendly interface that allows for simple operation and quick setup.
What is the maximum production speed? The machine can produce up to 25 meters per minute of air column film, depending on material and configuration.
What industries typically use air column bags? Air column bags are widely used in e-commerce, logistics, electronics, automotive, and retail packaging to protect fragile items during shipping.
