The Single Layer Kraft Paper Mailer Machine by Innopack is an advanced automated system for producing eco-friendly, tear-resistant kraft paper mailers at high speed. Featuring PLC control, servo motor precision, and integrated unwinding, embossing, slitting, folding, sealing, and adhesive application, it delivers lightweight, customizable, and recyclable mailers. Designed for e-commerce, logistics, and express delivery, it reduces shipping costs, boosts productivity, and meets sustainable packaging demands.
Model
INNO-PCL-1000
Material
Kraft Paper
Speed
40–80 bags/min
Width Range
≤1600 mm
Control
PLC + Servo Motor + Touch Screen
Application
Paper mailer production for e-commerce and logistics
The Single Layer Kraft Paper Mailer Machine from InnoPack is an advanced, high-speed system designed to produce Hexcel wrap, a revolutionary eco-friendly alternative to traditional plastic packaging materials like bubble wrap. The machine is equipped with precision die-cutting technology, automatic tension control, and a PLC control system for efficient, precise operation. The result is a high-performance machine that creates expandable honeycomb structures for protecting fragile goods during shipping and handling, making it an essential tool in modern sustainable packaging solutions.
Product Introduction
The Single Layer Kraft Paper Mailer Machine (INNO-PCL-1000) from Innopack is a pivotal piece of packaging machinery used in e-commerce and logistics to produce kraft paper mailers that are eco-friendly, tear-resistant, and lightweight. This machine takes a single roll of kraft paper and transforms it into custom-sized mailers that are perfect for shipping and packaging delicate items. The process starts with unwinding the paper, followed by embossing for enhanced protection, slitting to adjust the width, and cutting to create the desired length of the mailer.
Advanced models come with a PLC control system and servo motors for precise motion control, ensuring that each piece of paper is processed with high accuracy. The machine also includes a self-sealing adhesive strip, which is applied to the mailers for easy closure, and a strong sealing process that ensures the mailers are durable and secure.
By automating the production of kraft paper mailers, businesses can reduce their labor costs, increase productivity, and offer an environmentally responsible packaging solution that is both recyclable and biodegradable.
Technical Specifications
Model No:
INNO-FCL-1000
Material
Kraft paper
Speed of making Bag
40-80/min
Unwinding With
≦1600mm
Unwinding Diameter
≦1300mm
Machine Speed
90/min
Bag With
≦800mm
Bag Length
800mm
Voltage of Power Supply
380V,50HZ
Total Power
26KW
Machine Weight
3.8T
Machine Dimension
13600*2300*2280mm
Air Supply
Auxiliary Device
Key Features
High-Speed Production The Single Layer Kraft Paper Mailer Machine operates at 40–80 bags per minute, making it ideal for high-volume operations while maintaining top-quality production standards.
Eco-Friendly Packaging This machine produces tear-resistant kraft paper mailers, a biodegradable and recyclable alternative to plastic bubble wrap, reducing the environmental footprint of packaging.
Precision Control Equipped with a PLC control system and servo motors, the machine offers precise control over the entire packaging process, ensuring consistent quality and accurate cutting.
Automatic Folding and Sealing The machine performs automatic folding and sealing to create durable, secure mailers, and applies a self-sealing adhesive strip for easy and reliable closure.
Customizable Sizes The Paper Mailer Machine allows for the production of custom-sized mailers, making it versatile for various packaging needs in e-commerce and logistics.
Inline Printing Option Many models come with the option for inline printing, allowing for branding or product information directly printed on the mailer, creating a seamless branding opportunity.
Cost Reduction By automating the folding and sealing process, the machine reduces labor costs and increases efficiency in the order fulfillment process.
Sustainable Packaging Solution This machine helps businesses transition to eco-friendly packaging, meeting consumer demand for sustainable, plastic-free alternatives.
Applications
E-commerce: Ideal for packaging small to medium-sized items such as electronics, cosmetics, and clothing
Logistics: Suitable for shipping various products, ensuring safe delivery with minimal environmental impact
Food Packaging: Kraft paper mailers can be used for food-related shipments, offering a protective barrier
Retail Packaging: Perfect for high-end retail products, offering elegant and eco-friendly packaging
Specialized Mailers: Used for shipping invoices, documents, or contracts that need to be safely protected in transit
Why Choose Us
InnoPack is a leader in automated packaging technology, specializing in designing high-performance and eco-friendly packaging solutions. The Single Layer Kraft Paper Mailer Machine provides an efficient and sustainable solution for businesses looking to reduce their environmental impact while enhancing their packaging operations.
With a focus on precision, efficiency, and sustainability, InnoPack offers machinery that not only improves production speed but also reduces material waste and operational costs. By choosing InnoPack, you invest in an advanced solution that aligns with the growing demand for green packaging solutions.
Conclusion
The Single Layer Kraft Paper Mailer Machine by InnoPack provides businesses with an advanced, eco-friendly packaging solution for creating durable and customizable kraft paper mailers. With its high-speed production, precise folding and sealing, and the ability to produce biodegradable and recyclable mailers, this machine is ideal for industries seeking sustainable packaging options that do not compromise on performance. For businesses requiring protective void-fill materials, explore our Automatic Honeycomb Paper Making Machine. Choose InnoPack for a packaging solution that is both efficient and environmentally responsible.
FAQs
What materials can the machine handle? The machine processes kraft paper, which is a sustainable and eco-friendly material for producing mailers.
What is the maximum production speed? The machine can produce between 40 and 80 mailers per minute, depending on the size and complexity of the packaging.
Can the machine create custom-sized mailers? Yes, the machine is capable of producing custom-sized mailers to suit different packaging needs.
Is the machine eco-friendly? Yes, the machine produces biodegradable and recyclable kraft paper mailers, making it an eco-friendly alternative to plastic-based packaging.
Can the machine be integrated with inline printing? Yes, many models of the Single Layer Kraft Paper Mailer Machine come with an inline printing option for branding or product information.
